G. Stereoplotters

This Section is a very brief overview of stereoplotters. It's included to round out the discussion on stereophotography. Detailed geometry, stereomodel orintation, C_factors, etc, are not coverd for two reasons:

• The details are beyond the scope of the the basic photogrammetric theme of this topic.
• Analog systems have been largely replaced by digital systems (scanners, softcopy p[hotogrammetry, etc) so most of this information is primarly of historical nature.

For greater detail, please refer to one of the Photogrammetry textbooks.

1. What

Maps were compiled from analog aerial photos using a stereoplotter. A stereoplotter allowed the operator to directly view and map overlapping photos in 3D.

Instead of creating paper positives from film negatives, the images are developed on glass plates. The developed plates are called diapositives. Glass is rigid and more stable than paper-based pictures and allows light to pass through.

A stereoplotter consists of two projectors, each holding one dispositive of a stereopair. When oriented correctly the projectors replicate camera position and geometry. Light passing through the diapositives project corresponding images into a 3D viewing system.

There are three primary types of analog plotters:

• Optical
• Mechanical
• Opti-Mechanical

They are to photogrammetry what transits and total stations are to survey measurements - both accomplish the same things based on the same principles, but do so in a different fashion. Optical plotters are the older design of the two and have an open design (like a transit); mechanical plotters are enclosed, have a more efficient viewing system, and are more easily integrated with computers and digital data capture. Because they are simpler and easier to visualize, optical plotters will be used to describe the basic concepts.

2. Plotter Principles

An optical plotter has a movable light source in each projector, These illiminaute only a part of the diapositve. Each light source is connected to a tracing stand. The light projects the same image from both diapositives, Figure G-1, onto the tracing stand's platten, the center of which is a small illuminated dot.. The tracing stand sits on the manuscript on whilch the map is compiled. The plotter bed is a heavy piece of slate or similar material providing a solid stable base.

Figure G-1 Basic Stereoplotter Components

The illuminated dot on the platten appears to float in the 3D image, Figure G-2. Raising and lowering the platten causes the dot to float above (A), on (B), or below (C) the model surface.The vertical platten movement can be directly converted into elevation.

Figure G-2 Tracing Stand and Floating Dot

It is called an optical plotter because the floating point location is a function of the parallactic angle between the image projection lines. It is not the angle between the connection rods to the lights.

The operator adjusts the platten height until the floating dot appears to sit on the ground - this is an optical solution of the parallax equations. A pencil lead or scribe is located directly beneath the platten dot so by moving the tracing stand while keeping the floating dot on the ground (tracing the contour), the operator can trace a contour line on the manuscript. Planimetric features can be mapped similarly.

3. Types of Plotters

a. Optical

The most prevalent optical plotter was a Kelsh-stlye plotter, Figure G-3. It used full size 9"x9" diapositives. Its predecessors include the Multiplex and Ballplex potters, both of which used reduced size diapositives limiting their plotting accuracies.

Figure G-3 Kelsh-style Plotter

Notice the operator in Figure G-3 is working in a dark room: The only part of the model illuminated is that part projected onto the platten. Because the plotter is an open design, ambient light would wash out the 3D view on the platten.

To see the model in 3D, the operator's right eye must see only the right image, the left eye the left image.The reason was discussed in the previous chapter. On a steroplotter, one of three different systems was used to force each of the operator's eyes to view the correct image projection. Anaglyphic (red & blue lenses) and Polarized systems were described in the previous chapter. Another common system used synchroized rotating shutters. Each projector had its own shutter whose rotation was matched to one on the tracing stand.When one shutter set was closed, the other was open so only one eye saw its image at a time. The rotation was fast enough that the operator wasn't aware of the on-off shutter sequence. The shutter system was preferred because color photogtrahphy could be used (unlike the Anaglyphic System) and the image was brighter since no filters were used.

b. Mechanical

These are newer enclosed instruments, Figure G-4, which use precise optics to shorten and better control optical projection geometry.

Figure G-4 Mechanical Plotter

The operator sits and views the 3D model though a binocular system using prisms so filters and shutters aren't needed. Because it is an enclosed system, it needn't be operated in darkroom conditions.

The diapositives are mounted in carirers and can be moved horizontally in concert to view a specific overlap area. The operator uses handwheels (left-right, front-back) to control this motion. This takes the place of moving a tracing stand across the plotter bed.

Instead raising/lowering a platten with its illumiated dot, internal prisms are rotated to change the floating dot elevation, similar to a parallax bar. This vertical motion is operater-controlled using a footwheel. This makes floating dot placement more precise than possible with an optical plotter, Figure G-5.

Figure G-5 Mechanical Plotter Controls

Two spacerods connect the diapositive carriers with a pivot point in front of the operator. As the hand/foot wheels are turned, the spacerods move to recreate the image's parallactic angle. This space rod operation creates a mechanical connection between the diapositives and operator controls, hence the name mechanical plotter.

The map is compiled on an adjacent table using either a mecahnically connected plotting arm (pantograph) or a digital plottor.

c. Opti-Mechanical

This type is a cross between an optical and mechanical plotter having chracteristics of both, Figure G-6.

Figure G-6 Opti-Mechainical Plotter

The example in Figure G-6 uses a tracing stand similar to an optical machine but connects it to the diapositives using space rods like a mechanical one. The diapositives do not move and the operator views the model using a binocular/prism system maintaining correct optical geometry.

This example uses a pantograph connected to the tracing stand to directly plot the map.

d. Digital Integration

Unlike an optical stereoplotter, mechanical and opti-mechanical ones are highly adaptable to computer integration and digital data capture. Figure G-7 shows a collection of digitally-integrated mechanical plotters.

Figure G-7 Digital Mechanical Plotters
